MP0 SERIES ISOSCOPE DFT METER

Get a Price/Quote

Product Details:

Material ABS plastic body
Condition New
Technology Magnetic induction and eddy current
Portable Yes
Operating Temperature 0 to +50C
Humidity % 85% RH (non-condensing)
Sensors Specification Integrated probe for ferrous and non-ferrous substrates
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

MP0 SERIES ISOSCOPE DFT METER Price And Quantity

Minimum Order Quantity 1 Number

MP0 SERIES ISOSCOPE DFT METER Product Specifications

Usage Coating Thickness Measurement (Dry Film Thickness - DFT)
Power Consumption Low power consumption
Portable Yes
Operating Temperature 0 to +50C
Humidity % 85% RH (non-condensing)
Technology Magnetic induction and eddy current
Power Source 2 x 3V CR2032 lithium batteries
Working Voltage 3 V
Dimension (L*W*H) 109 x 44 x 20 mm
Indicator Specification LCD digital display
Material ABS plastic body
Condition New
Sensors Specification Integrated probe for ferrous and non-ferrous substrates
Weight Approx. 110 g (including battery)

Measurement Range 0 - 1250 m
Backlight No
Minimum Measuring Area 20 mm
Auto Power Off Yes
Measurement Units m, mils
Minimum Curvature Radius Convex: 1.5 mm, Concave: 25 mm
Minimum Substrate Thickness Ferrous: 0.5mm, Non-ferrous: 50 m
Battery Lifetime Approx. 30,000 measurements
Display Type Digital LCD
Data Storage No built-in memory
Accuracy (1.5 m + 2% of reading)
Application Paint, powder, plating, and coating industry
Probe Type Integrated
Calibration Zero and foil calibration
Standards Conformance DIN, ISO, ASTM, BS

MP0 SERIES ISOSCOPE DFT METER Trade Information

Delivery Time 7 Days

Product Description

Experience top-tier performance with the MP0 SERIES ISOSCOPE DFT METER-a popular choice for coating thickness measurement professionals. This brilliant masterpiece offers impressive savings through efficient, reliable results. Specially designed for the paint, powder, plating, and coating industries, it measures a broad range (0 - 1250 m) with exceptional accuracy and a digital LCD display. Its integrated probe swiftly assesses both ferrous and non-ferrous substrates, conforming to major global standards. Lightweight, portable, and robust, it's the preferred tool for dealers, manufacturers, and traders alike.

Advantage, Site of Application and Application Surface

The MP0 SERIES ISOSCOPE DFT METER delivers unmatched accuracy, making it a brilliant choice for inspecting dry film thickness on various surfaces. Ideal for on-site use in industries like automotive, manufacturing, and construction, it measures coatings on both convex and concave surfaces with ease. Its adaptability allows for reliable readings on ferrous and non-ferrous substrates, ensuring quality control on metal, powder-coated, and painted surfaces. Elevate your inspection process and ensure consistent outcomes every time.

Main Domestic Market, Supply Ability and Payment Terms

Our main domestic market benefits from prompt order processing and reliable goods transport. With excellent supply capability, we manage bulk and regular orders with precision, catering to a range of dealers, distributors, and wholesalers. Payment terms are straightforward to facilitate seamless transactions, ensuring our clients receive the MP0 SERIES ISOSCOPE DFT METER with maximum convenience. Trust us for efficient logistics, timely delivery, and consistent support as your dedicated supplier.

FAQ's of MP0 SERIES ISOSCOPE DFT METER:

Q: How does the MP0 SERIES ISOSCOPE DFT METER ensure accurate measurement results?

A: It utilizes magnetic induction and eddy current technology for precise readings, paired with zero and foil calibration methods to maintain accuracy.

Q: What surfaces and applications is this DFT meter designed for?

A: This device measures coating thickness on ferrous and non-ferrous substrates, making it suitable for paint, powder, plating, and coating industries across a range of curved or flat surfaces.

Q: Where can the MP0 SERIES ISOSCOPE DFT METER be efficiently used?

A: It is ideal for use on production floors, construction sites, automotive workshops, and quality control labs requiring dry film thickness measurements.

Q: How long does the battery last in regular usage?

A: The meter's two CR2032 lithium batteries provide approximately 30,000 measurements before needing replacement.

Q: What is the process for calibrating the DFT meter?

A: Calibration involves zero and foil procedures, ensuring each measurement is accurate according to recognized standards such as DIN, ISO, ASTM, and BS.

Q: What are the benefits of the auto power off feature?

A: Auto power off helps conserve battery life, maximizing usage and minimizing maintenance costs for busy industrial environments.
