Sigmascope SMP350

Product Description

Our company is well recognized in the market as a manufacturer and exporter of Sigmascope. This is a handheld instrument for conductivity measurement of non-ferromagnetic metals. Our research and development team is highly trained and they use latest technology in manufacturing of this instrument. Design of this handheld machine is very efficient and very easy to use. We deliver Sigmascope world wide at very affordable price with full care.

Features:

• Portable instrument
• Quick analog display
• Low maintenance



Further Details:

The SIGMASCOPESMP10 is a hand-held instrument which provides rapid, simple, on-the-spot and, if necessary contact free, measurement of the conductivity of non-magnetic metals.

The corresponding measurement probe ES40 operates at the measurement frequencies of 60 kHz, 120 kHz, 240 kHz and 480 kHz.

For automatic temperature compensation of the conductivity measurement the current temperature of the specimen can be measured using either the temperature sensor integrated in the probe ES40 or an optional external sensor.

For the conductivity measurements of very thin Aluminum platings of only about 0.2 mm thickness in the aircraft industry the SIGMASCOPE SMP10-HF is available. The measurement frequencies are 60 kHz, 240 kHz and 480 kHz with probe ES40 and 1.25 MHz with probe ES40-HF.

Applications

• Absolute measurement of electrical conductivity during the production process of aluminum copper, etc.
• Monitoring heat-treatment processes, strength and hardness of aluminum wrought alloys in the aerospace and automobile industries.
• Checking the electrical conductivity before anodizing aluminum.
• Determination of the degree of purity and scrap metal sorting.

Specification
