गोल्डस्कोप एसडी 600

Usage/Application

Testing, Tunch, Hallmarking , Jewellery Retail , Hallmarking and Assay Offices

Material

Aluminium

Application

Laboratory Use

Analysis Elements

GUsed, Copper, Silver, Platinum

Operation Mode

Automatic

Automation Grade

Automatic

Power Type

Electric

Accuracy

0.01

Speed

30 sec per sample

Detector

Silicon Drift Detector

Features

Analysis of gold, silver and other metals

Aperture Collimator

4x changeable .2 , .6 , 1 , 2 mm

Dimension

403 x 588 x 365 mm

Computer

HP

Count Rate

अधिक than 100000

Surface Finish

Metallic

Design

Benchtop

Detection Limit

Al to U

Display

LCD

Display Screen

PC

Element Range

Aluminum to Uranium including Iridium, Ruthenium , Osmium, Rhenium, Tin and Lead

Measuring Direction

Bottom Up

Radiation Protection

AERB Approved

Rated Power

AC 115 V or AC 230 V

Sample Positioning

Manually or Automatically

Sample Stage

Fixed sample support

Test Chamber Dimension

310 x 320 mm

Tube

Micro focus tube with tungsten target and beryllium window

X Ray Tube

Micro focus tube with tungsten target and beryllium window

Brand

FISCHER

Condition

New

Power Supply

AC 115 V or AC 230 V

Protection Class

IP40
